AMD AM5 Ryzen 7 9700X 5.5 GHz  8 Cores  16 Threads 65W CPU Overview

36 months

Specifications


General Data

Model Number 100-100001404WOF
Name AMD Ryzen™ 7 9700X
Family Ryzen
Series Ryzen 9000 Series
Form Factor Desktops , Boxed Processor
Market Segment Enthusiast Desktop
AMD Pro Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename Granite Ridge AM5
Architecture Zen 5
Number of CPU Cores 8
Multithreading (SMT) Yes
Number of Threads 16
Max. Boost Clock Up to 5.5 GHz (Max boost for AMD processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.)
Base Clock 3.8 GHz (Represents the average effective base frequency of all cores.)
L1 Cache 512 KB
L2 Cache 8 MB
L3 Cache 32 MB
Default TDP 65 W
Processor Technology for CPU Cores TSMC 4 nm FinFET
Processor Technology for I/O Die TSMC 6 nm FinFET
Package Die Count 2
Unlocked for Overclocking Yes (AMD`s product warranty does not cover damages caused by overclocking, even when overclocking is enabled via AMD hardware and/or software. GD-26.)
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimiser Voltage Offsets Yes
AMD Ryzen™ Master Support Yes
CPU Socket AM5
Supporting Chipsets A620 , X670E , X670 , B650E , B650 , X870E , X870
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB) Not Included
Recommended Cooler Premium air cooler recommended for optimal performance
Max. Operating Temperature (Tjmax) 95°C
OS Support Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bi

Connectivity

Native USB 3.2 Gen 2 (10Gbps) Ports 4
Native USB 2.0 (480Mbps) Ports 1
PCI Express® Version PCIe® 5.0
Native PCIe® Lanes (Total/Usable) 28 , 24
Additional Usable PCIe Lanes from Motherboard X870E: 8 x Gen4
X870: 4 x Gen4
X670E: 12 x Gen4
X670: 12 x Gen4
B650E: 8 x Gen4
B650: 8 x Gen4
NVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10
System Memory Type DDR5
Memory Channels 2
Max. Memory 192 GB
System Memory Subtype UDIMM
Max Memory Speed 2x1R: DDR5-5600
2x2R: DDR5-5600
4x1R: DDR5-3600
4x2R: DDR5-3600
ECC Support Yes (Requires mobo support)

Graphics Capabilities

Graphics Model AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
USB Type-C® DisplayPort™ Alternate Mode Yes

Key Features

Supported Technologies AMD EXPO™ Technology , AMD Ryzen™ Technologies
SKU CPUR79700X
Brand AMD
Unit Of Measure ea
