CyberPower VP1600ELCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes and brownouts. Designed with GreenPower UPS Technology.

24 months

  • Line-interactive UPS Topology
  • Generator Compatible
  • Automatic Voltage Regulation (AVR)
  • High-speed Ethernet Data Transmission
  • Surge and Spike Protection
  • PowerPanel Management Software
  • Energy Saving Technology
  • Simulated Sine Wave Output
  • LCD Status Display
  • USB Connectivity Port
  • Serial Connectivity Port

General

Model Number VP1600ELCD
Phase Single Phase
Form Factor Tower
UPS Topology Line-interactive
Energy Saving Technology GreenPower UPS™ Bypass Technology



Input

Generator Compatibility Yes
Nominal Input Voltage ( Vac ) 230 ± 10%
Input Voltage Range ( Vac ) 167 ~ 295
Input Frequency ( Hz ) 50 ± 5
60 ± 5
Input Frequency Detection Auto-sensing
Rated Input Current ( A ) 6.96
Input Connector Type IEC C14
Detachable Power Cord Plug Type AU x 1
Power Cord Length (ft.) 5
Power Cord Length (m.) 1.5



Output

Capacity (VA) 1600
Capacity (Watts) 960
On Battery Waveform Simulated Sine Wave
On Battery Voltage(s) ( Vac ) 230 ± 10%
On Battery Frequency ( Hz ) 50 ± 1%
60 ± 1%
Automatic Voltage Regulation (AVR) Single Boost, Single Buck
Overload Protection Circuit Breaker
Outlet(s) - Total 4
Outlet Type AU x 4
Outlet(s) - Battery & Surge Protected 3
Outlet(s) - Surge-Only Protected 1
Typical Transfer Time ( ms ) 4



Battery

Runtime at Half Load ( min ) 11
Runtime at Full Load ( min ) 2
Typical Recharge Time ( Hours ) 8
Start On Battery Yes
User-replaceable No
Battery Type Sealed Lead-acid



Surge Protection & Filtering

Surge Suppression ( Joules ) 450
EMI/RFI Filtration Yes
Phone/Network Protection RJ11/RJ45 (Combo) 1-in, 1-out



Management & Communications

LCD Panel Yes
LCD Information Display Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information
LCD Setting & Control Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning
LED Indicators Power On
HID Compliant USB Port(s) 1
Audible Alarms Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ) USB Cable x 1
Ethernet Data Transmission Speed Up to 1Gbps
Power Management Software PowerPanel®Personal (Recommended)



Physical

Enclosure Construction Plastic
Colour Black



Physical Size - UPS Module

Dimensions (WxHxD) (in.) 3.9 x 11 x 14
Dimensions (WxHxD) (mm.) 100 x 281 x 355
Weight (lbs.) 22.97
Weight (kg.) 10.42



Environmental

Operating Temperature (°F) 32 ~ 104
Operating Temperature (°C) 0 ~ 40
Operating Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Operating Elevation ( feet/meters ) 0-9,843 feet (0-3,000 meters)
Storage Temperature (°F) -4 ~ 122
Storage Temperature (°C) -20 ~ 50
Storage Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Storage Elevation ( feet/meters ) 0-9,843 feet (0-3,000 meters)
Online Thermal Dissipation ( BTU/hr ) 68
Audible Noise at 1.0M from Surface of Unit ( dBA ) 50



Certifications

Certifications CE, RCM
RoHS Yes



Warranty

Product Warranty Period (Year) 2
Battery Warranty Period (Year) 2
SKU UPSCVP1600ELCD
Brand CyberPower
Unit Of Measure ea
