Functions

Print, scan, copy, fax

PRINTER

Printing Technology

LED

Print Colour

Colour

Maximum Resolution

1200 x 600 dpi

Print Speed

Simplex: 35 ppm

Duplex: 27 ipm

Toner Cartridge Compatibility

Standard Cyan Toner Cartridge (~10,000 pages)

Standard Magenta Toner Cartridge (~10,000 pages)

Standard Yellow Toner Cartridge (~10,000 pages)

Standard Black Toner Cartridge (~10,000 pages)

High-Capacity Black Toner Cartridge (~15,000 pages)

First Print Out Speed

9.5 seconds

Duplex Printing

Automatic

Printer Duty Cycle

Monthly: 100,000 pages

Recommended Monthly Volume: 1,000 to 10,000 pages

SCANNER

Scanner Type

Colour flatbed

Duplexing/reversing automatic document feeder

Scan Resolution

600 dpi

Scan Speed

ADF: 1.2 sec/page

Flatbed: 2.0 sec/page

Maximum Scan Area

11.7 x 17" (29.7 x 43.2 cm)

Scanner Features

Scan-To Capabilities: Folder (CIFS/FTP/HTTP), email (with LDAP support), USB memory, PDF, Secure PDF, high compression-PDF, S-TIFF/M-TIFF (RAW/G3/G4 Compressed), JPEG, XPS, Scan to computer (with Actkey), Remote Scan, OCR and PDF/A supported with SENDYS Explorer LITE and ABBYY FineReader 12 Sprint

COPIER

Maximum Resolution

600 x 600 dpi

Copy Speed

Simplex: 35 cpm

Duplex: 17 ipm

First Copy-Out Time

10 seconds

Maximum Copy Size

11 x 17" (27.9 x 43.2 cm)

Duplex Copying

Yes

Quantity

Up to 999 copies

Reduction / Enlargement

25-400%

Copy Features

ID copy, collate, n-Up, mixed originals, edge and centre erase

FAX

Modem Speed

33.6 kbps Super G3

Connection

PSTN, PBX line

Fax Memory

8 MB (400 pages)

Touch Dials

40 programmable (8 x 5 using shift key)

Speed Dial Locations

1,000

Group Dials

32

Fax Features

On-hook dial, redial, fax from PC, internet fax (T.37), auto fax/telephone switch, distinctive ring detection, automatic tray select for fax print, block junk fax, edge erase, automated delivery, duplex scan/print, fax image preview on touchscreen

MEDIA HANDLING

Paper Handling

Main tray

Multi-purpose tray

Reversing automatic document feeder

Optional input trays 2, 3, and 4

Paper Capacity

Main Tray: 300 sheets

Multi-Purpose Tray: 100 sheets

ADF: 100 sheets

Optional 2nd, 3rd, an 4th Trays: 535 sheets each

Paper Sizes

Main Tray: Tabloid 11 x 17" (27.9 x 43.2 cm), legal 8.5 x 14" (21.6 x 35.6 cm), legal 13.5" and 13" (34.3 cm and 33.0   cm), letter 8.5 x 11" (21.6 x 27.9 cm), executive SEF 7.25 x 10.50" (18.4 x 26.7 cm)

Multipurpose Tray: 2.5 x 3.5" to 11.7 x 52.0" (6.4 x 8.9 cm   to 29.7 x 132.1 cm)

ADF: Tabloid 11 x 17" (27.9 x 43.2 cm), legal 8.5 x 14" (21.6 x 35.6 cm), folio 8.5 x 13" (21.6 x 33.0 cm), letter 8.5 x   11" (21.6 x 27.9 cm), executive SEF 7.25 x 10.50" (18.4 x 26.7 cm)

Optional Trays: Tabloid 11 x 17" (27.9 x 43.2 cm), legal 8.5 x 14" (21.6 x 35.6 cm), letter 8.5 x 11" (21.6 x 27.9 cm), executive SEF 7.25 x 10.50" (18.4 x 26.7 cm)

Media Weight

Main Tray: 17 lb bond to 100 lb vellum (60-220 gsm)

Multipurpose Tray: 17 lb bond to 140 lb index (64-256 gsm)

ADF: 16 lb to 32 lb bond (60-120 gsm)

Optional Trays: 17 lb bond to 65 lb cover (64-176 gsm)

Stapler

20-sheet off-line convenience stapler

CONNECTIVITY

Interfaces

Ethernet (10/100/1000 Base-TX)

USB 2.0

2 x USB host ports

Optional module for 802.11a/b/g/n Wi-Fi

Direct Print Capable

Yes, via USB host ports

OS Compatibility

Windows 8.1, 8, 7, Server 2003, Vista, Server 2008 R2, Server 2012 R2

Mac OS X 10.6.8-10.10

Linux PPD

Processor

800 MHz CPU

Memory

1.25 GB

Hard Drive Capacity

250 GB hard disk drive

Printer Language

PCL 5c, PCL 6, PostScript 3, PDF (v1.7), XPS, IBM ProPrinter, Epson FX

Security

IP and MAC filtering, IPSec, secure and encrypted secure print, SMTP server and POP before SMTP authentication, SSL security for SMTP protocol, SNMPv3, SSL/TLS encryption, port change

GENERAL ATTRIBUTES

Control Panel

7" (17.8 cm) colour tilting touchscreen display; alphanumeric keypad and function buttons

Power Requirements

120 VAC

Power Consumption

Peak: <1400 W

Average: <850 W

Standby: <120 W

Power Save: <30 W

Deep Sleep: <3 W

Off: <0.1 W

ENERGY STAR

Compliant

TEC Value: 3.5 kWh

Acoustic Noise

Operating: 54 dB(A)

Standby: 37 dB(A)

Dimensions

22.2 x 23.6 x 27.6" (56.3 x 60.0 x 70.0 cm) including ADF

Weight

141.1 lb (64 kg)
