Next-level SSD performance

Unleash the power of the Samsung PCIe 4.0 NVMe SSD 980 PRO for your next-level computing. Leveraging the PCIe 4.0 interface, the 980 PRO delivers double the data transfer rate of PCIe 3.0 while being backward compatible for PCIe 3.0 for added versatility.

* The NVM Express® design mark is a registered trademark of NVM Express, Inc.

Maximum speed

Powered by Samsung custom Elpis Controller for PCIe 4.0 SSD, the 980 PRO is optimized for speed. It delivers read speeds up to 7,000 MB/s, making it 2 times faster than PCIe 3.0 SSDs and 12.7 times faster than SATA SSDs. The 980 PRO achieves max speeds on PCIe 4.0 and may vary in other environments.

* Performance may vary depending on the SSD’s firmware version and the system hardware & system configuration. Performance measurements are based on IOmeter 1.1.0. The write performances were measured with Intelligent TurboWrite technology being activated. The sequential write performances after Intelligent TurboWrite region are: up to 500 MB/s(250GB), 1,000 MB/s(500GB) and 2,000 MB/s(1TB). * Test system configuration: AMD Ryzen 9 3900X 12-Core Processor CPU @ 3.79GHz, DDR4 2666MHz 16GBx2, OS-Windows 10 Pro 64bit, Chipset-ASUS-X570-ROG CROSSHAIR VIII FORMULA* Results are based on a comparison with Samsung PCIe 3.0 NVMe SSDs and SATA SSDs.* To maximize the performance of the 980 PRO, please check whether your system supports PCIe 4.0 at the Intel or AMD website.

A winning combination

Designed with hardcore gamers and tech-savvy users in mind, the 980 PRO offers high-performance bandwidth and throughput for heavy-duty applications in gaming, graphics, data analytics, and more. It's fast at loading games so you can play more and wait less.

Efficient M.2 SSD

The 980 PRO comes in a compact M.2 2280 form factor, which can be easily plugged into desktops and laptops for maximum board design flexibility. The drive is suitable for building high-performance computing systems due to its optimized power efficiency.

Reliable thermal control

High-performance SSDs usually require high-performance thermal control. To ensure stable performance, the 980 PRO uses nickel coating to help manage the controller's heat level and a heat spreader label to deliver effective thermal control of the NAND chip.

Smart thermal solution

Embedded with Samsung's cutting-edge thermal control algorithm, the 980 PRO manages heat on its own to deliver durable and reliable performance. To minimise performance fluctuations in the long haul, Samsung's Dynamic Thermal Guard technology maintains the 980 PRO's temperature at optimal levels.

Samsung Magician software

Unlock the full power of the 980 PRO with Samsung Magician's intuitive yet advanced optimisation tools. Monitor drive health, optimise performance, protect valuable data, and receive important updates with Magician to ensure you're always getting the best performance out of your SSD.

World's No. 1* Flash Memory

Experience superior performance and reliability that you can only get from the world's number one* seller of flash memory since 2003. All firmware and components, including Samsung's world-renowned DRAM and NAND, are produced in-house, allowing end-to-end integration for quality you can trust.

*Source: 2003-2019 IHS Markit data: NAND suppliers' revenue market share.

Specifications

Interface

PCIe Gen 4.0 x4, NVMe 1.3c

Sequential Read

Up to 7,000 MB/s *

* Performance may vary based on system hardware & configuration

Sequential Write

Up to 5,000 MB/s *

* Performance may vary based on system hardware & configuration

Warranty

5-Year Limited Warranty or 600 TBW Limited Warranty

Application

Client PCs

Weight

Max 9.0 g Weight

General Feature

Application

Client PCs

Rated Capacity

1,000GB (1GB=1 Billion byte by IDEMA)

* Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)

Form Factor

M.2 (2280)

Interface

PCIe Gen 4.0 x4, NVMe 1.3c

Dimension (WxHxD)

80.15 x 22.15 x 2.38 (mm)

Weight

Max 9.0 g Weight

Storage Memory

Samsung V-NAND 3-bit MLC

Controller

Samsung Elpis Controller

Cache Memory

Samsung 1GB Low Power DDR4 SDRAM

Special Feature

TRIM Support

Supported

S.M.A.R.T Support

Supported

GC (Garbage Collection)

Auto Garbage Collection Algorithm

Encryption Support

AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)

WWN Support

Not supported

Device Sleep Mode Support

Yes

Performance

Sequential Read

Up to 7,000 MB/s *

Sequential Write

Up to 5,000 MB/s *

Random Read (4KB, QD32)

Up to 1,000,000 IOPS *

Random Write (4KB, QD32)

Up to 1,000,000 IOPS *

Random Read (4KB, QD1)

Up to 22,000 IOPS *

Random Write (4KB, QD1)

Up to 60,000 IOPS *

* Performance may vary based on system hardware & configuration

Environment

Power Consumption

Average: 6.2 W* Maximum: 8.9 W (Burst mode)*

Power Consumption (Idle)

Max. 35 mW *

Allowable Voltage

3.3 V ± 5 % Allowable voltage

Reliability (MTBF)

1.5 Million Hours Reliability (MTBF)

Operating Temperature

0 - 70°C Operating Temperature

Shock

1,500 G & 0.5 ms (Half sine)

* Actual power consumption may vary depending on system hardware & configuration

Accessories

Installation Kit

Not Available

Software

Management SW

Magician Software for SSD management

Warranty

5-Year Limited Warranty or 600 TBW Limited Warranty

60 months

Specifications

Application	Client PCs
Capacity	1000GB (1GB=1 Billion byte by IDEMA) Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor	M.2 (2280)
Interface	PCIe Gen 4.0 x4, NVMe 1.3c
Dimension (WxHxD)	80.15 x 22.15 x 2.38 (mm)
Weight	Max 9.0 g Weight
Storage Memory	Samsung V-NAND 3-bit MLC
Controller	Samsung Elpis Controller
Cache Memory	Samsung 1GB Low Power DDR4 SDRAM
TRIM Support	Supported
S.M.A.R.T Support	Supported
GC (Garbage Collection)	Auto Garbage Collection Algorithm
Encryption Support	AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support	Not supported
Device Sleep Mode Support	Yes
Sequential Read	Up to 7,000 MB/s
Sequential Write	Up to 5,000 MB/s
Random Read (4KB, QD32)	Up to 1,000,000 IOPS
Random Write (4KB, QD32)	Up to 1,000,000 IOPS
Random Read (4KB, QD1)	Up to 22,000 IOPS
Random Write (4KB, QD1)	Up to 60,000 IOPS
Average Power Consumption (system level)	Average: 6.2 W Maximum: 8.9 W (Burst mode)
Power consumption (Idle)	Max. 35 mW
Allowable Voltage	3.3 V ± 5 % Allowable voltage
Reliability (MTBF)	1.5 Million Hours Reliability (MTBF)
Operating Temperature	0 - 70 ℃ Operating Temperature
Shock	1,500 G & 0.5 ms (Half sine)
Warranty	5 years
